Icop Vortex86 Little board

I got this years ago from a friend, it's very picky about power so i have never been able to power it from an usb powerbank or something, but 5v from a good 2A PSU is fine. The vortex is an interesting SOC, feels like a fast 486/Pentium, XP runs on this board but slowly, i remember i made a build of Windows CE 6? that had all the drivers for it but i can't find it now, but probably still doable, i used the icop ebox driver pack.

More info

• Solder seems to be brittle? i had to reflow several components on the bottom, like the ram and the ic next to it.
• it has I/O for everything, floppy, parallel port, etc but it needs custom cables made.
• not sure if the pc104 slot actually works or not, i have never got any reaction from the computer when i plug in cards.
• This computer is from around 2004 so it really likes 98 and up, i didn't test 95, and the audio soundcard only works on Windows and Linux, no DOS support at all.

Photos
